AZ31B hot rolled magnesium plate






Basic Information:
Place of Origin: |
Zhengzhou China (Mainland) |
Brand Name: |
SINOMAGNESIUM |
Certification: |
ISO9001:2000. SGS |
Model Number: |
AZ31 AZ91 ZK61M |
Minimum Order Quantity: |
20 Kilogram |
Price: |
Negotiable |
Packaging Details: |
Wooden Case |
Delivery Time: |
10-15 days |
Payment Terms: |
T/T, L/C, Western Union, MoneyGram, Paypal |
Supply Ability: |
5,000 Ton per year |
Detail Information
Product Name: |
Magnesium-based Plate |
Type: |
AZ31 AZ80 AZ61 AZ91 ZK61 |
Purity: |
≥94% |
Material: |
Magnesium Alloy |
Application: |
Textile Printing Machinery & Engraving Plate |
Surface Treatment: |
Polishing |
Shape: |
Plate, Sheet & Board |
Feature: |
High Specific Strength & Lightest Metal |
Appearance: |
Flat And Smooth |
Color: |
Silver And White |
Length: |
1 - 3000MM |
Width: |
1 - 2600MM |
Thickness: |
0.3 - 200MM |
Chemical Composition: |
Al Zn Mn Mg |
HS Code: |
81049020 |
OEM/ODM: |
Available |
High Light: |
ZK61M Magnesium Alloy Plate, AZ31 AZ91 Magnesium Alloy Plate, 94% Mg Al Alloy Sheet |
Product Description
OEM/ODM Hot Rolled AZ31 AZ80 AZ61 AZ91 ZK61 Magnesium Alloy Plate
Description
Although the specific gravity of magnesium alloy is heavier than plastic, its strength and elastic modulus per unit weight are higher than that of plastic. Therefore, with the same strength parts, magnesium alloy parts can be made thinner and lighter than plastic. In addition, because the specific strength of magnesium alloy is higher than that of aluminum alloy and iron, the weight of aluminum or iron parts can be reduced without reducing the strength of the parts.
Applications: The size of the LCD screens on mobile phones and laptops has increased year by year. Magnesium alloys are used on their support frames and back shells.
Our company produces high-quality extruded or rolled magnesium alloy plates with complete specifications and various grades, including AZ31B, AZ61, AZ80, AZ91, ZK60, ZK61, WE43, WE94, etc.
Specification
Good heat transfer: Although the thermal conductivity of magnesium alloy is not as good as that of aluminum alloy, it is dozens of times higher than that of plastic. Therefore, magnesium alloy used in electrical products can effectively dissipate internal heat to the outside.
Alloy and Temper | Thickness (mm) | Yield Strength 0.2% Offset (MPa) | Tensile Strength (MPa) | Elongation in 5.65√A (%) |
AZ31B-O | 0.5-1.5 | 125 | 221 | 10 |
1.5-6.3 | 105 | 221 | 9 | |
6.3-75 | 105 | 221 | 8 | |
AZ31B-H24 | 0.5-6.3 | 200 | 269 | 5 |
6.3-9.5 | 179 | 262 | 7 | |
9.5-12.7 | 165 | 255 | 8 | |
12.7-25 | 152 | 248 | 8 | |
25-50 | 138 | 234 | 6 | |
50-80 | 124 | 234 | 7 | |
AZ31B-H26 | 6.3-10 | 186 | 269 | 6 |
10-12.5 | 179 | 262 | 6 | |
12.5-20 | 172 | 255 | 5 | |
20-25 | 159 | 255 | 5 | |
25-40 | 152 | 241 | 5 | |
40-50 | 148 | 241 | 5 |
Application
Our product are widely used in transportation (automobiles, motorcycles, bicycles, rail transit, aviation); electronic products (computers, mobile phones, digital cameras, etc.); medical equipment (wheelchairs, crutches, rehabilitation fitness equipment, etc.) aerospace; textile High standards and diversified demands in the fields of printing machinery and automobiles.
Our Product and Technical Advantages
-
Professional & advanced magnesium alloy casting technology
-
Better elongation of magnesium alloy plate is much better
-
More uniform crystal size of magnesium alloy plate
-
Smaller size difference of magnesium alloy plate
-
The flatness of our magnesium alloy plate can reached 0.0001mm after special hot-pressing process
-
Customized magnesium alloy plate with thickness range from I - 200 mm
-
Advanced testing & inspection equipment
-
Premium after-sales service
AZ31 ZK61 AZ80 Magnesium Alloy Plate ODM Hot Rolled Magnesium Sheet

-
1.Can I order a sample quantity ?
A: Yes
-
2.Can I add my logo on the boxes/cartons?
A:Yes, OEM and ODM are available from us.
-
3.What are the benefits of being a distributor ?
A: Special discount Marketing protection.
-
4.How does your factory control the quality of your products?
A: 100% self-inspection before packing. Quality is the life of our factory, first, each raw materials, come to our factory, we will test, if qualified, we will process the manufacturing with this raw materials, if not, we will return it to our supplier, and after each manufacturing step, we will test it, and then all the manufacturing process finished, we will do the final test before the commodities left our factory.
-
5.Can we mix items in one 20FT container?
A: Yes
-
6.Can I have a visit to your factory before the order?
A: Sure, welcome your visit to our plant
