High purity Mg alloy heatsink






Basic Information:
Place of Origin: |
Zhengzhou China (Mainland) |
Brand Name: |
SinoMg |
Certification: |
ISO9001:2000. SGS |
Model Number: |
AZ91D |
Minimum Order Quantity: |
100 Piece |
Price: |
Negotiable |
Packaging Details: |
Carton |
Delivery Time: |
25-30 days |
Payment Terms: |
T/T, L/C, Western Union, MoneyGram, Paypal |
Supply Ability: |
1,000,000 Kilogram per month |
Detail Information
Items: |
Magnesium Heat Sink |
Model: |
AZ91D |
Material: |
Magnesium Alloys |
Application: |
Aviation, Electronic, Industrial & Chemical |
Standard: |
JIS,GB,DIN, BS, ASTM, AISI |
Purity: |
≥98% |
Alloy Or Not: |
Alloy |
Tolerance: |
+/-1%, +/-0.02MM |
Tech Process: |
Extrusion, Deburring, CNC Machining Checking & Packing |
Specification: |
As Per Designs |
Process Service: |
Ending, Welding, Punching,Cutting & Machining |
Surface Treatment: |
Painting,Powder Coating, Polishing & Electroplating |
OEM/ODM: |
Available |
HS Code: |
8104902090 |
High Light: |
Purity 98% Extruded Heat Sink Profiles, AZ91D Magnesium Extruded Heat Sink, Extruded Heat Sink Profiles AZ91D |
Product Description
Industrial Application Magnesium-Based Alloy Extruded Heat Sink AZ91D
Description
Magnesium alloys have advantages in heat dissipation relative to alloys. For heat sinks of magnesium alloy and aluminum alloy materials of the same volume and shape, the heat (temperature) produced by a certain heat source is easier to transfer from the root of the heat sink to the top of the magnesium alloy than the aluminum alloy. Speed, the top is easier to reach high temperature. That is, the temperature difference between the root and top of the radiator made of aluminum alloy material is smaller than that of the radiator made of magnesium alloy material. This means that the temperature difference between the air temperature at the root of the heat sink made of magnesium alloy and the air temperature at the top is larger than that of the heat sink made of aluminum alloy material, so it accelerates the diffusion and convection of the air inside the radiator and improves the heat dissipation efficiency. Therefore, at the same temperature, the heat dissipation time of magnesium alloy is not half that of aluminum alloy.
Weight: magnesium alloy is 36% lighter than aluminum alloy, 73% lighter than zinc, and 77% lighter than steel.
Some of magnesium's favourable properties include low specific gravity and a high strength-to-weight ratio. As a result, the material lends itself to a range of automotive, aerospace, industrial, electronic, biomedical, and commercial applications.
Specification
Magnesium alloys have advantages in heat dissipation relative to alloys. For heat sinks of magnesium alloy and aluminum alloy materials of the same volume and shape, the heat (temperature) produced by a certain heat source is easier to transfer from the root of the heat sink to the top of the magnesium alloy than the aluminum alloy.
Product Name |
Heatsink; Magnesium heat sink; Extruded heatsink; Heat sink extrusion |
Material |
AZ91D |
Detailed Size |
As per customers' design |
Max Aspect Ratio( Fin Height / Fin Gap) |
More than 20 times aspect ratio heatsink can be extruded by 800 Tons--6000 Tons extruding machines by most advanced technology |
Max Width |
Ultra wide extruded heatsink can be made by our unique friction welding technology |
Standard Mold Qty |
30,000+ sets standard molds in stock for your option,saving your R&D cost |
Sample Service |
Samples with differernt sizes are availabe for prototypes test within 1 week |
Production Process |
Profiles Extruding---Cutting---CNC Machining(Milling, Drilling,Tapping)---Deburring--- Cleaning--- Inspecting--Packing |
Surface Treatment |
Degreasing,(Black) Anodizing,Sand Blasting,Painting,Chromating and Laser marking |
Reference Standard |
GB/T 3190-2008, GB/T 14846-2008, ISO 2768 |
Experience |
More than 20 years professional manufacturing experience |
Application |
LED Lighting,Inverter,Welding Machine,Communication Device,Power Supply Equipment,Electronic Industry,Thermoelectric Coolers/Generator,IGBT/UPS Cooling Systems,etc. |

Magnesium alloy is the lightest metal structural material, its density is 1.75-1.90s/cm3; its specific strength is higher than aluminum alloy and steel, and slightly lower than the highest specific strength fiber reinforced plastics; its machinability is excellent, easy to process and The processing cost is low, and the processing energy is only 70% of aluminum alloy; its corrosion resistance is much better than that of low-carbon steel, which has exceeded the die-cast aluminum alloy A380; its vibration damping and electromagnetic shielding properties are far better than aluminum alloy.
Purity 98% Extruded Heat Sink Profiles AZ91D Magnesium Alloy

-
1.What characteristics make a heatsink a good one?
A: High heatsink surface;Good aerodynamics;Good thermal transfer within the heatsink;Perfect flatness of the contact area;Good mounting method.
-
2.How long is your delivery time?
A:Generally it is 5-10 days if the heatsinks are in stock. or it is 30-40 days for mass production
-
3.Do you provide samples ?
A: Yes, we could offer paid sample for prototypes testing if there is stock.we have thousands of standard heatsinks with different sizes and shapes.
-
4.What is your terms of payment ?
A: Usually 100% payment before shipment. For regular customers,the terms can be nogotiated.
