ZK60 magnesium plate for aerospace
Basic Information:
|
Place of Origin: |
Zhengzhou China (Mainland) |
|
Brand Name: |
SinoMg |
|
Certification: |
ISO9001:2000. SGS |
|
Model Number: |
WE43 WE54 WE94 |
|
Minimum Order Quantity: |
20 Kilogram |
|
Price: |
Negotiable |
|
Packaging Details: |
Wooden Case |
|
Delivery Time: |
10-15 days |
|
Payment Terms: |
T/T, L/C, Western Union, MoneyGram, Paypal |
|
Supply Ability: |
5,000 Ton per year |
Detail Information
|
Item: |
Mag-based Alloy Plate |
Model: |
AZ31 AZ61 AZ91 WE43 |
|
Purity: |
≥93% |
Material: |
Magnesium Alloy, Mg Alloys |
|
Application: |
Textile Print Machine And Engraving Bar |
Surface: |
Polishing |
|
Shape: |
Plate, Sheet, Bar & Board |
Feature: |
High Specific Strength, Light Metal |
|
Appearance: |
Flat And Smooth |
Color: |
Silver & White |
|
Length: |
1-3000 MM |
Width: |
1-2600 MM |
|
Thickness: |
0.3-200 MM |
Chemical Composition: |
Al Zn Mn Mg |
|
HS Code: |
8104902090 |
OEM: |
Yes |
|
High Light: |
M1E Rolled Magnesium Alloy Plate,WE43 Magnesium Alloy Plate,Purity 93% magnesium alloy sheet |
||
Product Description
Pure Rare Earth Metals WE43 WE54 WE94 Magnesium-Based Alloy Plate
Description
Although the thermal conductivity of magnesium alloy is not as good as that of aluminum alloy, it is dozens of times higher than that of plastic. Therefore, magnesium alloy used in electrical products can effectively dissipate internal heat to the outside.
Application range: Magnesium alloy is used in the casing and heat dissipation parts of computers and projectors that generate high temperatures inside. The use of magnesium alloy on the casing of the TV can achieve no heat dissipation holes.
Our company produces high-quality extruded or rolled magnesium alloy plates with complete specifications and various grades, including AZ31B, AZ61, AZ80, AZ91, ZK60, ZK61, WE43, WE94, etc.
Specification
Although the thermal conductivity of magnesium alloy is not as good as that of aluminum alloy, it is dozens of times higher than that of plastic. Therefore, magnesium alloy used in electrical products can effectively dissipate internal heat to the outside.
| Alloy and Temper | Thickness (mm) | Yield Strength 0.2% Offset (MPa) | Tensile Strength (MPa) | Elongation in 5.65√A (%) |
| AZ31B-O | 0.5-1.5 | 125 | 221 | 10 |
| 1.5-6.3 | 105 | 221 | 9 | |
| 6.3-75 | 105 | 221 | 8 | |
| AZ31B-H24 | 0.5-6.3 | 200 | 269 | 5 |
| 6.3-9.5 | 179 | 262 | 7 | |
| 9.5-12.7 | 165 | 255 | 8 | |
| 12.7-25 | 152 | 248 | 8 | |
| 25-50 | 138 | 234 | 6 | |
| 50-80 | 124 | 234 | 7 | |
| AZ31B-H26 | 6.3-10 | 186 | 269 | 6 |
| 10-12.5 | 179 | 262 | 6 | |
| 12.5-20 | 172 | 255 | 5 | |
| 20-25 | 159 | 255 | 5 | |
| 25-40 | 152 | 241 | 5 | |
| 40-50 | 148 | 241 | 5 |
Our product are widely used in transportation (automobiles, motorcycles, bicycles, rail transit, aviation); electronic products (computers, mobile phones, digital cameras, etc.); medical equipment (wheelchairs, crutches, rehabilitation fitness equipment, etc.) aerospace; textile High standards and diversified demands in the fields of printing machinery and automobiles.
Our Product and Technical Advantages
-
Professional & advanced magnesium alloy casting technology
-
Better elongation of magnesium alloy plate is much better
-
More uniform crystal size of magnesium alloy plate
-
Smaller size difference of magnesium alloy plate
-
The flatness of our magnesium alloy plate can reached 0.0001mm after special hot-pressing process
-
Customized magnesium alloy plate with thickness range from I - 200 mm
-
Advanced testing & inspection equipment
-
Premium after-sales service
Purity 93% WE43 M1E Magnesium Alloy Plate For Textile Print Machine
-
1.Can I order a sample quantity ?
A: Yes
-
2.Can I add my logo on the boxes/cartons?
A:Yes, OEM and ODM are available from us.
-
3.What are the benefits of being a distributor ?
A: Special discount Marketing protection.
-
4.How does your factory control the quality of your products?
A: 100% self-inspection before packing. Quality is the life of our factory, first, each raw materials, come to our factory, we will test, if qualified, we will process the manufacturing with this raw materials, if not, we will return it to our supplier, and after each manufacturing step, we will test it, and then all the manufacturing process finished, we will do the final test before the commodities left our factory.
-
5.Can we mix items in one 20FT container?
A: Yes
-
6.Can I have a visit to your factory before the order?
A: Sure, welcome your visit to our plant
