Magnesium AZ92A welding wire

Basic Information:

Place of Origin:

Zhengzhou China (Mainland)

Brand Name:

SinoMg

Certification:

ISO9001:2000. SGS

Model Number:

AZ92A

Minimum Order Quantity:

5 Kilogram

Price:

Negotiable

Packaging Details:

Roll and Wooden Case

Delivery Time:

10-15 days

Payment Terms:

T/T, L/C, Western Union, MoneyGram, Paypal

Supply Ability:

300,000 Kilogram per month

Detail Information

Product Name:

Magnesium Alloy Welding Wire

Material:

Magnesium Alloy

Brand:

AZ92A

Application:

Heating, Household Electrical

Melting Point:

International Standard

Surface:

Bright

Feature:

Welding Magnesium Alloy Steel

Diameter:

1.2mm 1.6mm 2.0mm 2.4mm 3.0mm 4.0mm 6.0mm

Packing:

15 Kg/Spool, 5 Kg/Tube

Weight:

1kg, 5kg, 15kg, 20kg

Usage:

Welding, All Welding Position

OEM:

Customized

High Light:

GB/T 5153 Magnesium Welding WireMagnesium Welding Wire AZ312.4mm AZ31 Magnesium Alloy wire

Product Description

Magnesium AZ92A Welding Wire For Industrial Pure Nickel Forgings And Castings

Description

Magnesium alloy welding wire can be used for forging and casting of various magnesium alloys such as optical instruments, aerospace, automotive parts, and civilian magnesium products.

Full range of product types, Ensure production capacity

Main market: US, Canada, Korea, Japan, Turkey, Germany, UK, Sweden etc.

Specification

We have advanced die-casting, extrusion, forging, rolling, casting processing production line and precision testing equipment. Can produce a variety of types of magnesium alloy and magnesium alloy products, and developed a high-strength magnesium alloy extruded sheet. Through the purification of ordinary magnesium, magnesium can be raised up to 99.99% of high purity.

AZ31 GB/T 5153
Elements Al Zn Mn Si Fe Cu Ni Others,total
Min% 2.40 0.50 0.15
Max% 3.60 1.50 0.4 0.10 0.005 0.05 0.005 0.3



AZ61 GB/T 5153
Elements Al Zn Mn Si Fe Cu Ni Others,total
Min% 5.50 0.5 0.15
Max% 6.50 1.50 0.40 0.10 0.005 0.05 0.005 0.3



AZ91 GB/T 5153
Elements Al Zn Mn Si Fe Cu Ni Be Others,total
Min% 8.5 0.45 0.17         0.0005
Max% 9.5 0.90 0.40 0.08 0.004 0.025 0.001 0.003 0.3



AZ92 AWS A5.19-1992
Elements Al Zn Mn Si Fe Cu Ni Be Others,total
Min% 8.3 1.7 0.15         0.0002
Max% 9.7 2.3 0.50 0.05 0.005 0.05 0.005 0.0008 0.3
Magnesium alloy welding wire is mainly used for welding of industrial pure nickel forgings and castings, such as container building, construction machine, railway construction, pressure vessel for semi-auto or automatic gas shielded welding wire.

Specification

Small density, lighter than Al, higher specific strength

Higher fatigue limit

Bigger impact load than Al

Better thermal conductivity

Good casting property

Dimensionally stable

Easy revocery

Subsititute for engineering plastics

High corrosion resistance

Specification & Products Display

Magnesium alloy welding wire is mainly used for welding of industrial pure nickel forgings and castings, such as container building, construction machine, railway construction, pressure vessel for semi-auto or automatic gas shielded welding wire.

Specification of Magnesium Alloy Welding Wire

Standard Diameter

1.0mm 1.2mm 1.6mm 1.8mm 2.0mm

Normal Diameter

0.5-8.0 mm

Brand

AZ31 AZ61A AZ80A AZ92 ZK61M WE43

Standard

ASTM B90 Standard

Advantages of our Company

Our company has now developed a formula and process for producing high-quality magnesium alloys, which are inimitable. Magnesium alloy welding wire produced with this formula and process can realize compatible welding between different magnesium alloy materials, that is, different materials of magnesium alloy can be welded with one kind of welding wire, and have the advantages of small thermal effect zone, deep welding penetration, and no blistering. In particular, the 1.2mm magnesium alloy welding wire produced uses a one-time extrusion process to replace the original extrusion and then drawing process. Relying on the excellent technical team in the industry, the company continuously expands the application range of magnesium alloy materials through technological innovation, product innovation and process innovation, and contributes to the development of my country's magnesium alloy industry.

Our company is currently a professional manufacturer of magnesium alloy welding wire in China. The magnesium alloy welding wire produced by the company has specifications such as 1.2mm, 2.4mm, 3.2mm, etc., all of which are produced by one-time extrusion molding process with stable quality. With these magnesium alloy welding wires, different types of magnesium alloys can be welded together. The heat effect zone of the welded parts is small and the weld strength is higher than the non-welded zone. The bicycle frames welded with these magnesium alloy welding wires can achieve more than 150,000 vibration tests without cracks.

The application of magnesium alloy welding wire completely solves welding problem of magnesium alloys, can promote the wide application of magnesium alloys in military, aerospace, and civil applications, can increase the total application of magnesium alloys in the country, and maximize the high reserves of magnesium alloys in the country propelling the magnesium industry into a stage of rapid development will bring a material revolution to our country.

AZ92A Magnesium Welding Wire

  • 1.Are you a factory or trading company?

    A: We are direct manufacturer located in Zhengzhou Henan province, and have our equipment

  • 2.Are your products customized?

    A:Yes, the products in the website are only the common type or the previous types, we can supply the new products according to your requirements or drawings

  • 3.I do not know how to use your product ?

    A: Do not worry ! We can supply technical guidance together with products

  • 4.How can I get some samples?

    A: Several samples are freely offered for buidling the business long-term relationships and let our customers believing the quality of our products

  • 5.How does your factory do regarding quality control?

    A: We passed ISO 9001 and SGS certificate
