Bracelet zinc scarificial anode

Basic Information:

Place of Origin:

Zhengzhou China (Mainland)

Brand Name:

SinoMg

Certification:

ISO9001:2000. SGS

Model Number:

Z65802

Minimum Order Quantity:

20 Kilogram

Price:

Negotiable

Packaging Details:

Wooden Case

Delivery Time:

10-15 Days

Payment Terms:

T/T, L/C, Western Union, MoneyGram, Paypal

Supply Ability:

100,000 Piece per Month

Detail Information

Item:

Zinc Sacrificial Anode

Model:

Z65802

Raw Materials:

Zinc Alloy

Purity:

≥95%

Shape:

Barcelet, Round, Trapezoid

Application:

Aviation, Electronic, Industrial, Medical & Chemical

Thickness:

0.5 MM - 300 MM

Width:

500 MM

Standard:

JIS, GB, DIN, BS, ASTM & AISI

Enviroment:

Sea Water, Fresh Water

Feature:

Water Heater

Color:

Silver, White

Surface:

Bright, Smooth

Sample:

Yes

OEM:

Yes

HS Code:

81043000

High Light:

Bracelet Zinc Anode, zinc anode for cathodic protection

Product Description

Bracelet Zinc-based Sacrificial Anode for Cathodic Protection

Description

Zinc anode is a kind of zinc component used to help galvanized steel and other objects. It is often used to prevent corrosion and help other materials corrode more slowly and last longer. The sacrificial zinc anode is also a part of a large system which gives objects corrosion resistant abilities.

They are common among metallic marine applications, such as boats with metal hulls and metal crab pots. Saltwater is very corrosive and will quickly rust the metal, unless the galvanic coupling (voltaic couple) is formed with the sacrificial zinc anode, which can greatly increasing its useful life in the water.

Zinc anode has been developed in SINO ZHENG for more than 20 years. With high capacity, current efficiency and high machine performance, sacrificial zinc anodes are widely used in cathodic protection of tank bottom, pipeline, and water pipe in soil environments.

Specification

Type: Zince anode

Specification: Casting round bar billet(Φ3-160*3000)

Remarks: According to the requirements of sawing and heat treatment

Product Name:

Zinc-based Sacrificial Anode

Material

Zinc alloy

Differnet Kinds

Casting rod, Extruded rod, Rod with steel cap, Flexible anode rod

Chemical Composition

GB/T

Property

Open-circuit voltage: 1.5-1.55V

Close-circuit voltage:1.45-1.50V

Actual capacitance: 1.105A.h/g

Current efficiency: 50% min

Steel Cap

stainless steel, galvannized, in black, coppper etc.

Application

Offshore pipelines; Subsea pipelines; Offshore steel piles.

Feature

High density and uniform thickness; Perfect core eccentricity ensuring uniform consumption; Quick and easy installation.



Electrochemical Properties and Chemical Composition

Electrochemical Properties Open Circuit voltage (V) Working voltage (V) Actual Capacitance (AH/KG)


 Efficiency
(%)

Consumption rate
Kg·(A·a)
Dissolve situation
In Sea (1 m A / c m) -1.09~-1.05 -1.05~-1.00        ≥780       ≥95        ≤11.23 The product is easy to fall off, and the surface dissolves in uniformity.
In Soil (0.03mA/cm) ≤-1.05  ≤-1.03         ≥530       ≥65         ≤17.25
Chemical Composition %
Zn Al Cd Fe Cu Pb Si
Balance 0.3-0.6 0.05-0.12 0.005max 0.005max 0.006max 0.125max

Bracelet Zinc-based Sacrificial Anode for Cathodic Protection

  • 1.Do you provide OEM/ODM service?

    A: Yes, OEM/ODM is welcome, we have the professional R&D team.They work for you all the time (design, tooling/mould, sample, mass production).

  • 2.How can I know your company further?

    A:Please leave message in website with you email or phone number, the sales manager will send the catalogue to you by email or call you directly.Also welcome to visit our company!

  • 3.How can I get the quotation, sample, mass production?

    A: Please show us the sizes/drawing of the parts you need, our business director will show you detailed quotation with the lead time of sample and mass production.

  • 4.How do you control the quality?

    A: The products are produced under ISO9001 & SGS certificate.
