AZ31B AZ61 AZ91D WE43 ZK60 Mg rod

Basic Information:

Place of Origin:

Zhengzhou China (Mainland)

Brand Name:

SinoMg

Certification:

ISO9001:2000. SGS

Model Number:

AZ31B AZ61 AZ91D AZ80 WE43 ZK60

Minimum Order Quantity:

100 Kilogram

Price:

Negotiable

Packaging Details:

Wooden Case

Delivery Time:

10-15 days

Payment Terms:

T/T, L/C, Western Union, MoneyGram, Paypal

Supply Ability:

15,000 Kilogram per month

Detail Information

Features:

Heating, Household Electrical

Product Name:

Magnesium Rods

Model Number:

AZ31B AZ61 AZ91D AZ80 WE43 ZK60

Diameter:

30-800 MM

Purity:

98%

Length:

500 - 4000 MM

Weight:

1kg, 5kg, 15kg And 20kg

Processing:

Extrude And Cast

Material:

Magnesium Alloys

Shape:

Round Rod

Color:

White, Silver And Grey

Application:

Aviation, Electronic, Industrial And Chemical Industry

Surface:

Smooth

Standard:

JIS, GB, DIN, BS, ASTM B-90 And AISI

Chemical Composition:

Mg Al Zn Mn Zr

Main Market:

US, Korea, Japan, Turkey, Germany, UK, Egypt

HS Code:

8104902090

OEM/ODM:

Available

High Light:

WE43 ZK60 Extruded Magnesium Rods, AZ61 AZ91D AZ80 Magnesium Rods,98% Purity magnesium round bar

Product Description

AZ31B AZ61 AZ91D AZ80 WE43 ZK60 Wide Range Extruded Magnesium Alloy Rod

Description

AZ31B is a wrought magnesium base alloy with good room-temperature strength and ductility combined with corrosion resistance and weldability. Increased strength is obtained by strain hardening with a subsequent partial anneal (H24 and H26 temper) Compared with conventional casting magnesium alloys, semi-continuous casting magnesium alloys are finer in the organization, more uniform on the ingredients, and more compact inside with higher strength and elongation.

Application: Applied to Magnesium Alloy plate, strip, tube, rod, profile, wire and the alloy ingot and slab used for them.

Standard: ASTM B90/B90M

Processing Technology: Extrusion and Casting

Features of magnesium alloy rod:

- Good ductility and corrosion resistance
- High electrical and thermal conductivity
- Good room temperature strength at room temperature
- Suitable for round, flat and square bars, pipes, plates and forgings
Size of magnesium alloy rod:
Type: AZ31B, ZK61M, AZ80A, AZ91D, M2M, ME20M, AZ40
Specification: Casting round bar billet(Φ3-160*3000)

Physical Propertiy

Density: 1.8
Coefficient of thermal expansion: 26.8 x 10-6K-1
Specific heat: 1040 Jkg-1k-1
Thermal conductivity: 76.9Wm-1k-1
Electrical resistivity: 92nΩm
Modulus of elasticity: 45 x 109Pa
Poissons ratio: 0.35
Melting range: 566 - 632°C.

Product Name

Magnesium Rod
Hot Rolled Magnesium Alloy Rod
Cold Rolled Magnesium Alloy Rod
Large Diameter High Strength Rare Earth Magnesium Alloy Rod
High Performance Magnesium Alloy Rod

Specification

Diameter: 30mm - 800mm

Length is required of customer

Product specification are tailored to customer's requirements

Item Magnesium Alloy Rod AZ31B AZ61 AZ91D AZ80 WE43 ZK60
Material Magnesium Rod
Thickness as customer's required
Width as customer's required
Length as customer's required
Size customize
Features of Magnesium Alloy Rod 1.fast heat dissipation,light and good rigidity
2.Good corrosion resistance and dimensional stability
3.Good impact resistance and wear resistance
4.Good absorption of vibration energy performance
5.high thermal and conductive properties
6.non magnetic, good shielding and non-toxic characteristics



Features of Megnesium Alloy

High specific strength, elastic modulus, good heat dissipation and eliminate shock resistance to withstand the shock load capacity than aluminum,organic matter and alkali resistance and good corrosion. Mainly used in aviation, aerospace, transportation, chemical, rockets and other industrial sectors. In the utility magnesium is the lightest metal and the proportion of magnesium is about 2/3 of aluminum, iron 1/4. It is the lightest metal in practical metal, high strength and high rigidity.

Grade Chemical Composition, %
Al Zn Mn Zr Si Fe Cu Ni Mg
AZ31 2.4-3.6 0.15-1.5 0.15-0.40   ≤0.10 ≤0.05 ≤0.05 ≤0.005 Balance
AZ40 3.0-4.0 0.20-0.80 0.15-0.50   ≤0.10 ≤0.05 ≤0.05 ≤0.005 Balance
AZ61                 Balance
AZ80 5.5-6.5 0.5-1.5 0.15-0.40   ≤0.10 ≤0.005 ≤0.05 ≤0.005 Balance
AZ91 8.5-9.5 0.45-0.90 0.07-0.40   ≤0.08 ≤0.004 ≤0.025 ≤0.001 Balance
ZK61 ≤0.05 5.0-6.0 ≤0.1 0.45-0.80 ≤0.05 0.05 ≤0.05 ≤0.005 Balance
M1A     1.2-2.0   0.1   0.05 0.01 Balance

Carving, aerospace, concrete tools, 3C (cell phone / camera / computer), water heater, refrigerator, gas pipelines etc.

AZ61 AZ91D AZ80 WE43 ZK60 Extruded Magnesium Rods 98% Purity

  • 1.Are you a factory or trading company?

    A: We are direct manufacturer located in Zhengzhou Henan province, and have our equipment as well as plant

  • 2.Are your products customized?

    A:Yes, the products in the website are only the common type or the previous types, we can supply the new products according to your requirements or drawings

  • 3.I do not know how to use your product ?

    A: Do not worry ! We can supply technical guidance together with products

  • 4.How can I get some samples?

    A: Several samples are freely offered for buidling the business long-term relationships and letting our customers believing the quality of our products

  • 5.How does your factory do regarding quality control?

    A: We passed ISO 9001 and SGS certificate
